Hi Everyone, I have NT 32-248. The locks on the pilothouse doors are in bad shape. The lock cores fall out of the cylinder. I called Southco, they seem to have purchased Morbello (the original maker of the door lock). Jessica found the new part number, MM01-433-50, and said they could manufacture the whole door locking mechanism for $418 per side. They won’t manufacture just the lock core. I only need the lock core. Has anyone else had this problem and found a solution that doesn’t require buying they whole assembly? Paul NT 32-248 Portsmouth, NH

Contact Nordic Tugs for a solution. Best of luck, Harry and Jane Bessie NT 32-238 > On Oct 18, 2024, at 3:34 PM, Paul Tangen via Sentoa <sentoa@lists.sentoa.org> wrote: > >  > Hi Everyone, > I have NT 32-248. The locks on the pilothouse doors are in bad shape. The lock cores fall out of the cylinder. I called Southco, they seem to have purchased Morbello (the original maker of the door lock). Jessica found the new part number, MM01-433-50, and said they could manufacture the whole door locking mechanism for $418 per side. They won’t manufacture just the lock core. I only need the lock core. > > Has anyone else had this problem and found a solution that doesn’t require buying they whole assembly? > > Paul > NT 32-248 > Portsmouth, NH > > _______________________________________________ > Sentoa mailing list -- sentoa@lists.sentoa.org > To unsubscribe send an email to sentoa-leave@lists.sentoa.org

I had the same problem on NT32-251. It turned out to be a pretty simple fix. There’s a snap ring that holds the core in. The snap ring had broken. The pieces were inside the door. You can get at the latch/ lock mechanism by removing the lower section of door edge trim. My local ACE hardware had the snap rings in both plane steel and stainless steel. I obviously chose SS. It took a bit of trial and error plus a snap ring tool to get the correct size. Picture below (if that’s allowed). ~Tom Patterson NT 342-251 PACIFIC LOON Pt. Richmond, CA > On Oct 18, 2024, at 12:34 PM, Paul Tangen via Sentoa <sentoa@lists.sentoa.org> wrote: > > Hi Everyone, > I have NT 32-248. The locks on the pilothouse doors are in bad shape. The lock cores fall out of the cylinder. I called Southco, they seem to have purchased Morbello (the original maker of the door lock). Jessica found the new part number, MM01-433-50, and said they could manufacture the whole door locking mechanism for $418 per side. They won’t manufacture just the lock core. I only need the lock core. > > Has anyone else had this problem and found a solution that doesn’t require buying they whole assembly? > > Paul > NT 32-248 > Portsmouth, NH > > _______________________________________________ > Sentoa mailing list -- sentoa@lists.sentoa.org > To unsubscribe send an email to sentoa-leave@lists.sentoa.org

Thanks Tom, that’s a great idea. The picture did come through. I will get some snap rings. Paul NT 32-248 Greta Marie Portsmouth, NH > On Oct 18, 2024, at 4:46 PM, Tom Patterson <tpatterson888@gmail.com> wrote: > > I had the same problem on NT32-251. It turned out to be a pretty simple fix. There’s a snap ring that holds the core in. The snap ring had broken. The pieces were inside the door. You can get at the latch/ lock mechanism by removing the lower section of door edge trim. My local ACE hardware had the snap rings in both plane steel and stainless steel. I obviously chose SS. It took a bit of trial and error plus a snap ring tool to get the correct size. Picture below (if that’s allowed). > > ~Tom Patterson > NT 342-251 > PACIFIC LOON > Pt. Richmond, CA > > > >> On Oct 18, 2024, at 12:34 PM, Paul Tangen via Sentoa <sentoa@lists.sentoa.org> wrote: >> >> Hi Everyone, >> I have NT 32-248. The locks on the pilothouse doors are in bad shape. The lock cores fall out of the cylinder. I called Southco, they seem to have purchased Morbello (the original maker of the door lock). Jessica found the new part number, MM01-433-50, and said they could manufacture the whole door locking mechanism for $418 per side. They won’t manufacture just the lock core. I only need the lock core. >> >> Has anyone else had this problem and found a solution that doesn’t require buying they whole assembly? >> >> Paul >> NT 32-248 >> Portsmouth, NH >> >> _______________________________________________ >> Sentoa mailing list -- sentoa@lists.sentoa.org >> To unsubscribe send an email to sentoa-leave@lists.sentoa.org > > <IMG_0625.JPG>
